Thickened PE/PA construction for high-capacity vertical conveying of grains with D Type Elevator Buckets

Product Description

D-Type buckets are heavy-duty deep-style buckets developed by JINGWEI CONVEYOR, specifically designed for high-load agricultural and industrial material handling. Optimized from North American prototypes and incorporating domestic elevator structural features, these buckets are manufactured using high-strength polyethylene (PE) or reinforced nylon (PA), offering exceptional wear resistance, impact strength, and corrosion resistance.

As an upgraded and thickened version of the DS deep-type bucket, the D-Type is ideal for high-capacity, high-frequency material conveyance, including grains, feed, fertilizers, and mineral powders. Its deep-bucket design minimizes material spillage and enhances loading efficiency. Additionally, it is fully compatible with international HD/CC series buckets, allowing for easy replacement and interchangeability.

Key Features

1. Heavy-Duty Design

• Features thickened bucket walls and reinforced construction to withstand high-capacity vertical conveying of abrasive and impact-resistant materials such as grains, ores, and other bulk solids.

• Engineered for extended service life in demanding industrial environments with minimal wear and deformation.

2. Material Optimization

• Polyethylene (PE) Buckets: Lightweight yet highly durable, offering excellent corrosion resistance for food-grade, chemical, and pollution-sensitive applications. Ideal for grain handling and pharmaceutical industries where material purity is critical.

• Reinforced Nylon (PA) Buckets: Superior tensile strength and abrasion resistance, specifically designed for harsh applications involving mineral powders, sand, gravel, and other highly abrasive materials. Performs reliably under extreme loads and continuous operation.

3. Enhanced Compatibility

• Fully interchangeable with globally recognized HD/CC series buckets, ensuring seamless integration with existing equipment.

• Reduces downtime and replacement costs during system upgrades or maintenance, providing a cost-effective alternative to OEM parts.

4. High-Efficiency Loading

• Deep-bucket geometry minimizes material spillage and maximizes fill rates, significantly improving conveying capacity.

• Incorporates the optimized "(Z-Y)+10%" volumetric design to balance material retention and discharge efficiency, enhancing overall throughput.

Applications

1. Agricultural Applications

• Grain Storage & Processing: Specially designed for efficient and contamination-free vertical conveying of wheat, corn, soybeans, and other bulk grains. Ideal for silos, flour mills, and feed mills where hygiene and gentle material handling are critical.

• Feed Production: Ensures smooth elevation of animal feed ingredients while minimizing degradation or separation of nutritional components.

2. Industrial Applications

• Fertilizers & Chemicals: Corrosion-resistant PE/PA construction safely handles powdered or granular fertilizers, industrial salts, and chemical raw materials without degradation.

• Plastics & Polymers: Non-stick surface properties prevent buildup when conveying plastic pellets, recycled flakes, or compound materials in production lines.

3. Mining & Construction Materials

• Mineral Powders: Reinforced nylon buckets withstand abrasive materials like alumina, silica, and cement clinker with minimal wear.

• Aggregates: Heavy-duty design for continuous operation with sand, gravel, and crushed stone in batching plants and quarry operations.

4. Import Substitution Program

• HD/CC Series Compatibility: Direct replacement for international bucket standards (e.g., RUD, Tapco) with 100% dimensional interchangeability.

• Cost-Effective Alternative: Provides OEM-equivalent performance at competitive pricing, reducing downtime during bucket replacement in imported elevator systems.

• Localized Support: Faster delivery and technical assistance compared to overseas suppliers, minimizing production interruptions.

D&S Series Deep Type Bucket（HDPE & NYLON）

• D and S series belong to heavy agricultural type deep winnowing pan, also is the improvement of DS type deep winnowing pan thick.

• According to north American prototype bucket of this series, fully integrated domestic elevator design characteristics and our design concept.

• This series can be used with foreign HD/CC winnowing pan series, S series is corresponding to the D series back height variation type bucket.

• Recommended minimum bucket is winnowing pan "C" + 25 mm size, can be adjusted according to request of lifting capacity winnowing pan installation spacing;

• Suggest hoist speed 2.5 meters/seconds or less, can improve the nose wheel diameter size, due to throw food Angle change and adjusted;

• Recommend using (Z-Y)+10% as usable capacity for engineering design.

The data in the table is based on HDPE material, and the corresponding data of nylon material is +1.5% on this basis
